漏洞标题
scsi: zfcp: Fix double free of FSF request when qdio send fails
漏洞描述信息
In the Linux kernel, the following vulnerability has been resolved:
scsi: zfcp: Fix double free of FSF request when qdio send fails
We used to use the wrong type of integer in 'zfcp_fsf_req_send()' to cache
the FSF request ID when sending a new FSF request. This is used in case the
sending fails and we need to remove the request from our internal hash
table again (so we don't keep an invalid reference and use it when we free
the request again).
In 'zfcp_fsf_req_send()' we used to cache the ID as 'int' (signed and 32
bit wide), but the rest of the zfcp code (and the firmware specification)
handles the ID as 'unsigned long'/'u64' (unsigned and 64 bit wide [s390x
ELF ABI]). For one this has the obvious problem that when the ID grows
past 32 bit (this can happen reasonably fast) it is truncated to 32 bit
when storing it in the cache variable and so doesn't match the original ID
anymore. The second less obvious problem is that even when the original ID
has not yet grown past 32 bit, as soon as the 32nd bit is set in the
original ID (0x80000000 = 2'147'483'648) we will have a mismatch when we
cast it back to 'unsigned long'. As the cached variable is of a signed
type, the compiler will choose a sign-extending instruction to load the 32
bit variable into a 64 bit register (e.g.: 'lgf %r11,188(%r15)'). So once
we pass the cached variable into 'zfcp_reqlist_find_rm()' to remove the
request again all the leading zeros will be flipped to ones to extend the
sign and won't match the original ID anymore (this has been observed in
practice).
If we can't successfully remove the request from the hash table again after
'zfcp_qdio_send()' fails (this happens regularly when zfcp cannot notify
the adapter about new work because the adapter is already gone during
e.g. a ChpID toggle) we will end up with a double free. We unconditionally
free the request in the calling function when 'zfcp_fsf_req_send()' fails,
but because the request is still in the hash table we end up with a stale
memory reference, and once the zfcp adapter is either reset during recovery
or shutdown we end up freeing the same memory twice.
The resulting stack traces vary depending on the kernel and have no direct
correlation to the place where the bug occurs. Here are three examples that
have been seen in practice:
list_del corruption. next->prev should be 00000001b9d13800, but was 00000000dead4ead. (next=00000001bd131a00)
------------[ cut here ]------------
kernel BUG at lib/list_debug.c:62!
monitor event: 0040 ilc:2 [#1] PREEMPT SMP
Modules linked in: ...
CPU: 9 PID: 1617 Comm: zfcperp0.0.1740 Kdump: loaded
Hardware name: ...
Krnl PSW : 0704d00180000000 00000003cbeea1f8 (__list_del_entry_valid+0x98/0x140)
R:0 T:1 IO:1 EX:1 Key:0 M:1 W:0 P:0 AS:3 CC:1 PM:0 RI:0 EA:3
Krnl GPRS: 00000000916d12f1 0000000080000000 000000000000006d 00000003cb665cd6
0000000000000001 0000000000000000 0000000000000000 00000000d28d21e8
00000000d3844000 00000380099efd28 00000001bd131a00 00000001b9d13800
00000000d3290100 0000000000000000 00000003cbeea1f4 00000380099efc70
Krnl Code: 00000003cbeea1e8: c020004f68a7 larl %r2,00000003cc8d7336
00000003cbeea1ee: c0e50027fd65 brasl %r14,00000003cc3e9cb8
#00000003cbeea1f4: af000000 mc 0,0
>00000003cbeea1f8: c02000920440 larl %r2,00000003cd12aa78
00000003cbeea1fe: c0e500289c25 brasl %r14,00000003cc3fda48
00000003cbeea204: b9040043 lgr %r4,%r3
00000003cbeea208: b9040051 lgr %r5,%r1
00000003cbeea20c: b9040032 lgr %r3,%r2
Call Trace:
[<00000003cbeea1f8>] __list_del_entry_valid+0x98/0x140
([<00000003cbeea1f4>] __list_del_entry_valid+0x94/0x140)
[<000003ff7ff502fe>] zfcp_fsf_req_dismiss_all+0xde/0x150 [zfcp]
[<000003ff7ff49cd0>] zfcp_erp_strategy_do_action+0x160/0x280 [zfcp]
---truncated---
CVSS信息
N/A
漏洞类别
N/A
漏洞标题
Linux kernel 安全漏洞
漏洞描述信息
Linux kernel是美国Linux基金会的开源操作系统Linux所使用的内核。 Linux kernel存在安全漏洞，该漏洞源于zfcp驱动中FSF请求ID类型不匹配导致双重释放，可能导致内存损坏。
CVSS信息
N/A
漏洞类别
其他
